Multiple-gash hobs
2021-11-11 08:51:01
jiangxingTools
3288
Multiple-gash hobs
module: m1-m6
number of gashes for hobs: 13, 15, 17,19,20,21 or 24
KHSS-E EMo5Co5-TiN or AP coated
Recommeded structural dimensions for multiple-gash hobs as following；
Please contact us for more details on multiple-gash hobs, involute gear hob, chain sprocket hob, worm gear hob, spline hobs, timing belt pulley hob, etc HSS Gear Hobber Cutters.
